Linear Gauges
5-10
The Block Parameters dialog box governs the interaction between Simulink
and the ActiveX control embedded in the block. See “Summary of Dialog Box
Fields and Check Boxes” on page 3-29 for details.
Pointers
Display one or more pointers on the block (The Digital
panel uses the
PointerID property to reference the
pointers defined here.)
Scales
Define the range(s) and locations of values displayed on
the block (The
Bands, Pointers and Ticks panels use
the
ScaleID property to reference the ranges defined
here.)
Ticks
Display markers and/or numbers at intervals along the
scale
Panel Purpose
