Angular Gauges
5-4
The Block Parameters dialog box governs the interaction between Simulink
and the ActiveX control embedded in the block. See “Summary of Dialog Box
Fields and Check Boxes” on page 3-29 for details.
Library
Refer to property settings as a named collection
Needles
Display one or more needles on the block (The Digital
panel uses the
NeedleID property to reference the
needles defined here.)
Scales
Define the range(s) and locations of values displayed on
the block (The
Annulars, Hubs, Needles and Ticks
panels use the
ScaleID property to reference the ranges
defined here.)
Ticks
Display markers and/or numbers at intervals along the
scale
Panel Purpose
