System Generator for DSP Getting Started Guide www.xilinx.com 91
UG639 (v 12.2) July 23, 2010
Lesson 6 - Designing Filters
Lab Exercise: Designing Filters
In this lab you will be using the Filter Compiler block to generate optimized filters for the
Virtex®-5 architecture.
The lab instructions and lab design are located in the System Generator software tree at the
following pathname:
<ISE_Design_Suite_tree>/sysgen/examples/getting_started_training/lab7/
