System Generator for DSP Getting Started Guide www.xilinx.com 85
UG639 (v 12.2) July 23, 2010
Lesson 5 - Using Memories
Lab Exercise: Using Memories
In this lab you will learn how to use a Xilinx ROM block to implement a LUT-based
operation such as an Arcsin using Block RAM or Distributed RAM. This provides an
efficient implementation for trig and math functions with inputs that can be quantized to
10 bits or less.
The lab instructions and lab design are located in the System Generator software tree at the
following pathname:
<ISE_Design_Suite_tree>/sysgen/examples/getting_started_training/lab6/
