Chapter 4: Getting Started
Shared Memory Block
System Generator provides a simple abstraction for easily adding custom logic into a processor. The basic idea is to
allow memories in custom logic to be easily mapped into the processor's memory address space. System Generator
enables this through the use of Shared-Memory blocks provided in the System Generator block set.
