Lesson 4 - Multi-Rate Systems
Lab Exercise: Multi-Rate Systems
In this lab you will be exploring the effects of the rate changing blocks available in System
Generator. These blocks include Upsample, Downsample, Serial to Parallel and Parallel to
Serial.
The lab instructions and lab design are located in the System Generator software tree at the
following pathname:
<ISE_Design_Suite_tree>/sysgen/examples/getting_started_training/lab5/
