38 www.xilinx.com System Generator for DSP Getting Started Guide
UG639 (v 12.2) July 23, 2010
Chapter 3: Release Information
MathWorks MATLAB® Version 2009a or 2009b MATLAB must be installed in a directory
with no spaces (e.g., C:\MATLAB\R2009a)
Fixed-Point Toolbox required for signals
greater than 53 bits
MathWorks MATLAB®, Simulink with Fixed-
Point Toolbox Version 2009a and 2009b
MATLAB must be installed in a directory
with no spaces (e.g., C:\MATLAB\R2009a)
Fixed-Point Toolbox required for signals
greater than 53 bits
Table 3-6:
Linux-Based Requirements Notes
