User`s guide

C24x PWM
3-16
3C24x PWM
Purpose Generate code that configures the event manager (EV) modules to generate
PWM waveforms
Library c2400dspchiplib in Embedded Target for TI C2000 DSP
Description LF2407 DSPs include a suite of pulse width modulators (PWM) used to
generate various signals. This block provides options to set the A or B module
event managers to generate the waveforms you require. The twelve PWMs are
configured in six pairs, with three pairs in each module.
Module — Specifies which target PWM pairs to use:
•
A — Displays the PWMs in module A (PWM1/PWM2, PWM3/PWM4, and
PWM5/PWM6)
•
B — Displays the PWMs in module B (PWM7/PWM8, PWM9/PWM10, and
PWM11/PWM12)
Note PWMs in module A use the Event Manager A, Timer 1, and PWMs in
module B use Event Manager B, Timer 3. You should make sure that the
TimerClock selected in the Scheduling section of the LF2407 eZdsp Target
Preferences block does not conflict with the timers used for the PWMs.
Waveform period source — Source from which the waveform period value is
obtained. Select
Specify via dialog to enter the value in Waveform period or
select
Input port to use a value from the input port.
Waveform period — Period of the timer used to generate PWM waveform
measured in clock cycles. The relationship betwen the timer period and the
waveform period depends on the
Waveform type.
Note Clock cycles refers to the system CPU clock on the LF2407 chip. This
clock is 40 MHz.
Waveform type — Type of waveform to be generated by the PWM pair. The
LF2407 PWMs can generate two types of waveforms:
Asymmetric and
