Purpose Generate code to configure the C24x analog-to-digital converter
c2400dspchiplib in Embedded Target for TI C2000 DSP
Description The C24x ADC block configures the C24x ADC to perform analog-to-digital
conversion of signals connected to the selected ADC input pins. It outputs
digital values representing the analog input signal and stores the converted
values in the result register of your digital signal processor. You use this block
to capture and digitize analog signals from external sources such as signal
generators, frequency generators, or audio devices.
The output of the C24x ADC is a vector of
uint16 values. The output values
are in the range 0 to 1023 because the C24x ADC is 10-bit converter.
The C24x ADC block supports ADC operation in dual-sequence and
cascaded-sequencer modes. In dual-sequencer mode, either
Module A or
Module B can be used for the ADC block, and two ADC blocks are allowed in
the model. In cascaded-sequencer mode, both
Module A and Module B are
used for a single ADC block.
Module — Specifies which DSP module to use
•
A — Displays the ADC channels in module A (ADCINA0 through
ADCINA7)
•
B — Displays the ADC channels in module B (ADCINB0 through
ADCINB7)
•
A and B — Displays the ADC channels in both modules A and B (ADCINA0
through ADCINA7 and ADCINB0 through ADCINB7)
Use the check boxes to select the desired ADC channels.
Sample time — Time in seconds between consecutive sets of samples that are
converted for the selected ADC channel(s). This is the rate at which values are
read from the result registers. See “Scheduling and Timing” on page 1-8 for
additional information on timing.
To set different sample times for different groups of ADC channels, you must
add separate C24x ADC blocks to your model and set the desired sample times
for each block.
