User`s guide
Table Of Contents
- Getting Started
- Using the IQmath Library
- Block Reference
- Blocks — Alphabetical List
- Absolute IQN
- Arctangent IQN
- C24x ADC
- C24x CAN Receive
- C24x CAN Transmit
- C24x From Memory
- C24x PWM
- C24x To Memory
- C28x ADC
- C28x eCAN Receive
- C28x eCAN Transmit
- C28x From Memory
- C28x PWM
- C28x To Memory
- Division IQN
- F2812 eZdsp
- Float to IQN
- Fractional part IQN
- Fractional part IQN x int32
- Integer part IQN
- Integer part IQN x int32
- IQN to Float
- IQN x int32
- IQN x IQN
- IQN1 to IQN2
- IQN1 x IQN2
- LF2407 eZdsp
- Magnitude IQN
- Saturate IQN
- Square Root IQN
- Trig Fcn IQN
- Index
1
Getting Started
This chapter describes how to use the Embedded Target for TI C2000 DSP to create and execute
applications on Texas Instruments C2000 development boards. To use the targeting software, you
should be familiar with using Simulink to create models and with the basic concepts of Real-Time
Workshop automatic code generation. To read more about Real-Time Workshop, refer to your
Real-Time Workshop documentation.
What Is the Embedded Target for the
TI TMS320C2000 DSP Platform?
(p. 1-2)
Introduces the Embedded Target for TI C2000 DSP and
describes some of its features and supported hardware
Setting Up and Configuring (p. 1-3) Describes the software and hardware required to use the
Embedded Target for the TI TMS320C2000 DSP Platform
and how to set them up
Embedded Target for TI C2000 and
Code Composer Studio (p. 1-7)
Information about Code Composer Studio
Scheduling and Timing (p. 1-8) Information about C2000 scheduling
Overview of Creating Models for
Targeting (p. 1-10)
Summary of steps required to create models for your
target
Using the c2000lib Blockset (p. 1-14) Example of creating a model and targeting hardware
