Using the c2000lib Blockset
1-17
Click Yes to allow automatic setup. The following simulation parameters are
set:
The default
Target configuration - System target file is ti_c2000.grt.tlc,
because you need to purchase and install the optional Real-Time Workshop
Embedded Coder to use the
ti_c2000_ert.tlc.
Note One Target Preference block must be in each target model at the top
level. It does not connect to any other blocks, but stands alone to set the target
preferences for the model.
Tab Page Field Setting
Solver
Stop time
inf
Solver
Type
Fixed-step
discrete
Workspace I/O
Save to workspace - Time
off
Workspace I/O
Save to workspace - Output
off
Advanced
Production hardware
characteristics
Microprocessor
Advanced
Number of bits for C 'char'
16
Advanced
Number of bits for C 'short'
16
Advanced
Number of bits for C 'int'
16
Advanced
Number of bits for C 'long'
32
Real-Time
Workshop
Target configuration - System
target file
ti_c2000_grt.tlc
Real-Time
Workshop
Target configuration - Template
makefile
ti_c2000_grt.tmf
