1 Getting Started
1-16
For more information on each block, refer to its reference page.
Setting Up the Model
Preliminary tasks for setting up a new model include adding a Target
Preferences block, setting or verifying Target Preferences, and setting the
simulation parameters.
1 Select New from the File menu to create a new Simulink model.
2 Double-click the Target Preferences library in c2000lib to open it.
3 Drag the F2812 eZdsp block into your new model.
The following dialog appears, asking if you want preferences to be set
automatically.
F2812 eZdsp
