Hard-Disk Read/Write Head Controller
9-27
Now try the root locus again with the plant and compensator as open loop.
rlocus(oloop)
zgrid
This time, the poles stay within the unit circle for some time (the lines drawn
by
zgrid show the damping ratios from to 1 in steps of 0.1). This plot
showsa setof poles
'+' selected using rlocfind. A t the MATLAB prompt, type
[k,poles] = rlocfind(oloop)
k
k =
4.1179e+03
ζ
0
=
