Notice the foll o wing about the models lis ted in the Systems list on the
right-click menu:
• The names reflect the title of the Simulink model.
• The version number is incremented every time
Get Linearized Model is
sele cted.
• The LTI Viewer simultaneousl y displ ay s the response plots of all of the
checked models listed.
Saving Analysis Models
The analysis models obtained each t ime you select GetLinearizedModelare
stored only in the Simulink LTI Viewer workspace. You can save these models
into th e main M ATLAB w orksp ace by s e lect ing
Export from the Simulink LTI
Viewer
File menu.
Selecti n g
Export opens t he window shown below.
Lists all the analysis models
currently in the Simulink LTI Viewer
Store the selected
analysis model in
a MAT-file.
Store the selected
analysis model in
the MATLAB workspace.
workspace.
