For example to display only the first row of models in the 2-by-3 LTI array m2d,
either:
• Select the first index in the first listbox (corresponding to the first dimension
of the LTI array) with your mouse.
• Type the vector
[1] in the textbox below the first listbox.
The following figure depict the
Model Selector for LTI Arrays window for
sele cting to dis p lay the responses of the first row of models in the LTI arra y
m2d.
Figure 6-15: LTI Array Model Selector to Select the First Row of m2d
ThenextfigureshowstheLTIViewerdisplaythatresultsfromselectingApply
or OK.
Select OK or Apply to
implement your LTI array model
