OnceyouhaveselectedthenameofanLTIarrayintheModel Selector for
LTI Arrays
window, you can select models in the LTI array whose response
plots you want displayed using either or both of the following:
• Index into the array d imensions of the LTI array (
IndexintoDimensions)
•Index into LTI array using design specification criteria (
Bound on
Characteristics
)
Indexing into the Array Dimensions of an LTI Array
To index into the array dimensions of an LTI Array:
1 Select Index into Dimensions in the Selection Criteria listbox. This item
is initially selected for you by default.
2 Leave the show selected tabasis(orchangeittohide selected). This
allows you to use your mouse or the textboxes to index into each dimension
of the LTI array.
3 Select indices of models whose plots you want displayed (or hidden) using
the listboxes corresponding to the dimensions of the LTI a rray by either:
- Using your mouse (using the
Control key for multiselection) to select
model indices from each array dimension of the LTI array (from each
listbox)
- Typing a vector of indices or any MATLAB expression that specifies a
vector of indices in the textbox below the listbox
4 Select Apply to implement your model selection choice without closing the
window, or
OK to implement your model selection choice and close t he
Model Selector for LTI Arrays window.
Note: Choosing the sho w all tab while in the Indexing into Dimensions
selection criterion is equivale nt to selecting all o f the indice s in the listboxes.
However, any previous selections you made using the
Indexing into
Dimensions
selectio n criterion are not lost. They can be rei nstalled by
applying show selected.
