Your LTI Viewer looks like this.
Figure 6-8: Nyquist Plots of the Four I/O Responses in ssF8
Notice th at the I/O names for this model appear on the Nyquist plot. Each of
the four plots displayed represents the I/O response from a single input to a
single output.
This plot region is
displayed as a grid
of four distinct
plots: one for each
I/O response of
ssF8.
