1 Right -click anywherein theplotregionof thestepresponseplots.This opens
the following menu list in the plot region.
Figure 6-1: The Right-Click Menu for SISO Models
2 Place your mo u se pointer on the Characteristics menu item, and select
Settling Time with your left mouse button.
Figure 6-2: The Step Response Characteristics Submenu
3 Right-click anywhere in the plot regio n ofthe Bode plots to open a right-click
menu.
4 Place your mou s e po inter on the Characteristics menu item.
The submenu items of the
Characteristics menu for the Bode plot are
different than those of the
Characteristics menu for the step response
right-click menu.
Figure 6-3: Bode Plot Characteristics Submenu
5 Select Peak Response with your left mouse button.
