5 Model Analysis Tools
5-4
Model Dynamics
The Control System Toolbox offers commands to determine the system poles,
zeros,DCgain,norms,etc.Youcanapply thesecommands tosingleLTImodels
or LTI arrays. The following table gives an overview of these commands.
With the exception of
norm, these commands are not supported for FRD
models.
Model Dynamics
covar
Covariance of response to white noise.
damp
Natural frequency and damping of system poles.
dcgain
Low-frequency (DC) gain.
dsort
Sort discre te - time poles by ma gnit ud e.
esort
Sort continuous-time poles by real part.
norm
Norms of LT I system s ( and ).
pole, eig
System poles.
pzmap
Pole/zero map.
zero
System transmission zeros.
H
2
L
∞
L
∞
