13 SISO Design Tool Reference
13-26
Root Locus Right-Click Menus
Note Click on items in the right-click menu pictured below to get help
contents.
.
Note that the menus are slightly different from those of the Bode diagram
right-click menus. See “Bode Diagram Right-Click Menus” for a description of
those menus.
Add
The Add menu options give you the ability to add dynamics to your
compensator design. This figure shows the
Add submenu.
The following pole/zero configurations are available:
•
Real Pole
•Complex Pole
•Integrator (pole at 0)
•
Real Zero
