Labels Page
Note Click on the page tabs below to get help on pages in the Root Locus
Property Editor.
You can use the
Label page to specify plot titles and axis labels. To specify a
new label, type the string in the appropriate field. The root locus plot
automatically updates.
Limits Page
Note Click on the page tabs below to get help on pages in the Root Locus
Property Editor.
The SISO Design Tool specifies default values for the real and imaginary axes
ranges to make sure that all the poles and zeros in your model appear in the
