Customizing Plots Inside the SISO Design Tool
9-11
Customizing Plots Inside the SISO Design Tool
Customizing plots inside the SISO Design Tool issimilar to how you customize
any response plot. The Control System Toolbox provides a property editor
specific to the SISO Design Tool that you can use to create custom root locus
and Bode diagrams within the SISO Design Tool.
Opening the Root Locus Plot Editor
There are three ways to open the Property Editor for root locus plots:
•Double-click in the root locus away from the curve
•Select
Properties from the right-click menu
•Select
Root Locus and then Properties from Edit in the menu bar
Note Click on the page tabs below to get help on pages in the Root Locus
Property Editor.
This figure shows the
Property Editor: Root Locus window.
