4. Let’s now set the following Zone-specific parameters thusly (note that “Unassigned
Number” means a MIDI controller number that is unassigned on the target Module):
Zone 1 Zone 2
Parameter Value Parameter Value
Channel 1 Channel 2
MIDIBank 2 MIDIBank 5
MIDIProgram 3 MIDIProgram 112
LowKey C6 LowKey F4
HighKey G7 HighKey B5
FootSwitchDestination 64 ModWheelDestination 1
FootSwitchMode Momentary ModWheelEntryState 0
FootSwitchEntryState Off ModWheelExitState 0
FootSwitchExitState Off All Other Controller Destinations Unassigned
Number
All Other Controller Destinations Unassigned
Number
All Other Controller Entry States 0
All Other Controller Entry States 0 All Other Controller Exit States 0
All Other Controller Exit States 0
Zone 3 Zone 4
Parameter Value Parameter Value
Channel 3 Channel 4
MIDIBank 3 MIDIBank 0
MIDIProgram 67 MIDIProgram 23
LowKey C3 LowKey E1
HighKey E4 HighKey B2
ControlKnobFunction1Destination 7 ControlKnobFunction1Destination 7
ControlKnobFunction1EntryState 127 ControlKnobFunction1EntryState 127
ControlKnobFunction1ExitState 127 ControlKnobFunction1ExitState 127
All Other Controller Destinations Unassigned
Number
All Other Controller Destinations Unassigned
Number
All Other Controller Entry States 0 All Other Controller Entry States 0
All Other Controller Exit States 0 All Other Controller Exit States 0
5. Let’s now set the MIDI receive channels on each of the Modules in our rig. Note that
they will be same as the channels of their corresponding Zone:
Module Channel
Module1 1
Module2 2
Module3 3
Module4 4
6. Finally, let’s now save our newly-created Setup. Recall that the Save button is illuminated.
To save our Setup, press the Save button once. The Save button LED will blink to
indicate that a save operation is underway, and the User Bank LED will also be lit. The
default save location will be the next available location in the Setup User Bank. If all
