Wet/Dry Vacuums 240-5239 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator's Manual. Save These Instructions For Future Reference.
TABLE OF CONTENTS SECTION PAGE Safety Instructions & Warnings.......................................................................................................2 Double Insulation Instructions.........................................................................................................4 Extension Cords..............................................................................................................................4 Unpacking & Checking Carton Contents............................
SAFETY INSTRUCTIONS & WARNINGS The purpose of safety symbols is to attract our attention to possible dangers. The safety symbols, and the explanations with them, deserve your careful attention and understanding. The symbol warnings do not by themselves eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
SAFETY INSTRUCTIONS & WARNINGS IMPORTANT SAFETY INSTRUCTIONS FOR FUTURE REFERENCE Read and understand this operator's manual and all labels on the Wet/Dry Vacuum cleaner before operating. Safety is a combination of common sense, staying alert, and knowing how your vacuum works. Use this Wet/Dry Vac only as described in this manual. To reduce the risk of personal injury or damage to your Wet/Dry Vac, use only Masterforce TM recommended accessories. Household Type SAVE THIS MANUAL FOR FUTURE REFERENCE.
DOUBLE INSULATION INSTRUCTIONS This Wet/Dry Vac is double-insulated, eliminating the need for a separate grounding system. Use only identical replacement parts. Read the instructions for Servicing Double-Insulated Wet/Dry Vacs before servicing. Use this Wet/ Dry Vac as described in this manual. Observe the following warnings that appear on the motor housing of your Wet/Dry Vac. DOUBLE INSULATED - GROUNDING NOT REQUIRED - WHEN SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.
UNPACKING & CHECKING CARTON CONTENTS Remove all contents from the box. Remove the power head and take out any contents inside the collection tank. Check each item against the carton contents list.
UNPACKING & CHECKING CARTON CONTENTS Push/Pull Handle With Soft Grip Cord Wrap Hook Tool Storage Bag Handle Power Head On-Off Switch Accessory Storage Vacuum Port Collection Tank Rear Wheel Accessory Storage Caster Foot Caster Drain Page 6
GENERAL ASSEMBLY INSTRUCTIONS A Philips head screwdriver is required. WARNING: DO NOT PLUG POWER CORD INTO POWER OUTLET, MAKE SURE PLUG IS DISCONNECTED BEFORE ASSEMBLING THE WET/DRY VAC. 4. Remove the contents from inside the collection tank. Make sure you have all contents as listed on page 5. (fig. 4) Fig. 4 UNPACKING YOUR WET/DRY VACUUM & GENERAL ASSEMBLY 1. Verify that the power cord is disconnected from the outlet. (fig. 1) Fig. 1 5.
GENERAL ASSEMBLY INSTRUCTIONS 7. Insert the wheel axle into the rear wheel housing. Insert a washer onto the axle followed by rear wheel and insert another washer. Insert the ‘R’ locking pin into the hole on the end of the axle to lock the wheel. Snap the hub cap onto the wheel. Repeat the same steps at the other end of the axle. (fig. 7) Fig. 9 Fig. 7 10. Your vacuum comes ready for dry vacuum cleaning. If cartridge filter is not installed refer to page 17 for filter installation. (fig. 10 & 11) Fig.
GENERAL ASSEMBLY INSTRUCTIONS 12. For wet vacuum cleaning, install the supplied foam wet filter. (fig. 13) For filter installation instructions, refer to page 18. Fig. 13 13. Place the power head back on the collection tank, aligning the top section with the latches, and snap into place. (fig. 14) Fig. 14 14. Insert the locking end of the hose into the vacuum port and turn to lock into place. (fig. 15) Fig. 15 Page 9 15. Choose the desired accessories and push onto the suction tube. (fig. 16) Fig.
DRY VACUUM OPERATION DRY VACUUMING WARNING: B E S U R E T O R E A D , UNDERSTAND, AND APPLY INFORMATION, ENTITLED ‘SAFETY INSTRUCTIONS & WARNINGS’. DO NOT VACUUM IN AREAS WIT H F LAMMABLE GASES, VAPO RS, OR EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT TYPE CLEANERS, OILBASED PAINTS, GASOLINE, ALCOHOL OR AEROSOL SPRAYS. EXPLOSIVE DUSTS INCLUDE BUT ARE NOT LIMITED TO: COAL, MAGNESIUM, GRAIN OR GUN POWDER.
DRY VACUUM OPERATION OPERATING INSTRUCTIONS: DRY VACUUMING 5. Insert the locking end of the hose into the vacuum port and lock in place. Push the required attachment onto the free end of the hose or extension. (fig. 6) 7. Turn the motor on by lipping the switch to the ‘I’ ON position. (fig. 8) Fig. 8 Fig. 6 8. Once you have completed vacuuming, flip the switch to the ‘O’ OFF position and unplug the power cord from the outlet. O = OFF 6. Plug the power cord into the outlet. (fig.7) Fig.
LIQUID VACUUM OPERATION LIQUID VACUUMING WARNING: BE SURE TO READ, UNDERSTAND, AND APPLY INFORMATION, ENTITLED ‘SAFETY INSTRUCTIONS & WARNINGS’. DO NOT VACUUM IN AREAS WIT H F LAMMABLE GASES, VAPO RS, OR EXPLOSIVE DUSTS IN THE AIR. FLAMMABLE GASES OR VAPORS INCLUDE BUT ARE NOT LIMITED TO: LIGHTER FLUID, SOLVENT TYPE CLEANERS, OILBASED PAINTS, GASOLINE, ALCOHOL, OR AEROSOL SPRAYS. EXPLOSIVE DUSTS INCLUDE BUT ARE NOT LIMITED TO: COAL, MAGNESIUM, GRAIN, OR GUN POWDER.
LIQUID VACUUM OPERATION 5. Turn the motor on by lipping the switch to the ‘I’ ON position. (fig. 5) Fig. 5 6. After use, empty the collection tank by unscrewing the drain cap. Drain liquids into a suitable receptacle or drain. Remember to refit the drain cap to the collection tank after draining collection tank. (fig. 6) Fig.
BLOWER OPERATION This Wet/Dry Vac has blowing capabilities. To use the blower feature follow the instructions listed. WARNING: ALWAYS WEAR SAFETY GOGGLES COMPLYING WITH ANSI Z87.1 (or in Canada, CSAZ94.3) BEFORE USING BLOWER. 4. Insert the locking end of the hose into the blower port on the back of the power head and lock into position. (fig. 3) Fig. 3 CAUTION: K E E P B Y S T A N D E R S CLEAR FROM BLOWING DEBRIS. WARNING: WEAR A DUST MASK IF BLOWING CREATES DUST THAT MIGHT BE INHALED. 1.
BLOWER OPERATION 7. Before turning on the vac, firmly hold loose end of the hose. Turn the motor on by flipping the switch to the ‘I’ ON position. (fig. 6) Fig.
MAINTENANCE WARNING: ALWAYS DISCONNECT THE PLUG FROM THE POWER OUTLET BEFORE REMOVING THE POWER HEAD FROM THE COLLECTION TANK. Fig. 4 1. Verify that the power cord is disconnected from the outlet. (fig. 1) Fig. 1 5. Clean the foam wet filter by washing it with water and mild soap. (fig.5) Fig. 5 2. Disconnect the hose from the vacuum. (fig.2) Fig. 2 6. Check the hose, attachments, and power cord to verify that they have not been damaged. 3.
INSTALLING & CLEANING CARTRIDGE FILTER Installing Cartridge Filter 1. Verify that the power cord is disconnected from the outlet. (fig. 1) Fig. 1 Removing and Cleaning Cartridge Filter 1. Unlock and remove the filter retainer by turning retainer handle counterclockwise. 2. Carefully remove the cartridge filter by sliding it off the filter cage. (fig. 6) Fig. 6 2. Remove power head and place in upside down position. 3.
INSTALLING & CLEANING FOAM WET FILTER Installing Foam Wet Filter Cleaning Foam Wet Filter 1. Verify that the power cord is disconnected from the outlet. (fig. 1) 1. With the removed power head in an upside down position, carefully remove foam wet filter. (fig. 4) Fig. 1 Fig. 4 2. Remove power head and place in upside down position. Follow instructions to remove cartridge filter in the section above. 3.
TROUBLESHOOTING WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK-UNPLUG BEFORE TROUBLESHOOTING. Symptom Possible Causes 1) No power supply. Vacuum will not operate. 2) Faulty power cord. 3) Collection tank full. Corrective Action 1) Check power supply – cord, breakers, fuses. 2) Unplug and check the power cord. If damaged, have it repaired by a professional. 3) Empty collection tank. Dust comes out from motor cover. 1) The cartridge filter is missing 1) Attach or replace cartridge or damaged. filter.
EXPLODED VIEW & PARTS LIST Key 1 2 3 4 5 6 7 8 9 10 11 12 Description Handle Assembly Power Head Assembly Filter Basket Assembly Cartridge Filter Latch Assembly Push/Pull Handle Receiver Collection Tank Vacuum Port Assembly Caster Foot Assembly Drain Cap With Gasket Rear Wheel Housing Wheel Axle Part # 551298101 551298111 240-5250 551298104 551207103 551002112 551002111 551002110 551115105 551131109 Qty Key Description 13 Rear Wheel Assembly 1 1 14 Push/Pull Handle Assembly 1 14.
NOTES Page 21
Wet/Dry Vacuums WARRANTY 90-DAY MONEY BACK GUARANTEE This MASTERFORCE TM brand wet/dry vacuum carries our 90-Day Money Back Guarantee. If you are not completely satisfied with your MASTERFORCETM brand wet/ dry vacuum for any reason within ninety (90) days from the date of purchase, return the vacuum with your original receipt to any MENARDS® retail store, and we will provide you a refund - no questions asked.
