INSTALLING & CLEANING FILTERS

2. Unlock the filter door by sliding the lock tab

UP to the unlocked position and pull the

door out. (fig. 2 & 3)

Fig. 2 Fig. 3

3. Remove the HEPA filter cartridge from the

vacuum. (fig.4)

Fig. 4

4. Clean filter by brushing dirt off. For optimal

performance a new filter is recommended.

(fig.5)

Fig. 5

5. Install the cleaned or new filter. (fig. 6)

Fig. 6

6. Insert the filter door tabs into the upper slots

and lock the filter door into place. (fig. 7 & 8)

Fig. 7 Fig. 8
