Assembly Instructions

Page 14 Page 15
ASSEMBLY AND OPERATION
2-DOOR BASE CABINET
Carefully separate the front and back
panels, allowing the side panels to unfold
completely.
Carefully lay the cabinet on its back on a
soft surface to protect the finish.
INSERT THE LIP OF THE BOTTOM
PANEL INTO THE SLOT ON THE BACK
OF THE CABINET, MAKING SURE THAT
THE HOLES ALIGN.
TILT THE BOTTOM PANEL ONTO THE
BOTTOM OF THE CABINET.
Attach the bottom panel to the cabinet
using eleven M6 x 16 Phillips head bolts.
Up
Down
Continue on the next page
Assembly is VERY EASY, however there are a few key steps that must be followed.
THESE KEY STEPS ARE HIGHLIGHTED IN BOLD CAPS. FOLLOW THESE TO EXPEDITE ASSEMBLY.
ASSEMBLY AND OPERATION
Screw four adjustable feet into the bottom
of the cabinet.
Attach the work top to the cabinet using
four M6 x 16 Phillips head tapping bolts.
Install two brackets to the inside top of
the cabinet side and work top using four
M6 x 16 Phillips head bolts. The brackets
will make the side panels stronger.
Hole
Insert four shelf supports inside the cabinet
at the desired height.
Note: to use the locking mechanism, the
shelf must be placed in the center position.
Place the shelf on the shelf supports.
The maximum shelf
capacity should be no more than 150 lbs
CAUTION:
