20V Lithium-Ion Battery Pack 252-8030 OPERATOR’S MANUAL CAUTION: To Reduce The Risk Of Injury, User Must Read And Understand Operator’s Manual. Save These Instructions For Future Reference. For questions / comments, technical assistance or repair parts – Please Call Toll Free: 1-866-917-4374. (M-F 8:30am - 5:00pm Est.
TABLE OF CONTENTS Safety Symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2 Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3 Overview/Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6 Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
SAFETY SYMBOLS Some of these following symbols may be used on this tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and more safely.
SAFETY INSTRUCTIONS The purpose of safety symbols is to attract your attention to possible dangers. The safety symbols and the explanations with them deserve your careful attention and understanding. The symbol warnings do not, by themselves, eliminate any danger. The instructions and warnings they give are no substitutes for proper accident prevention measures.
SAFETY INSTRUCTIONS WARNING: Read all safety warnings and instructions! Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The “term power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. WARNING: Risk of fire and electric shock. Dry location use only. Do not expose to rain. Risk of injury. WORK AREA SAFETY 1.
SAFETY INSTRUCTIONS 2. Know your power tool. Read the Instruction Manual carefully. Learn the tool’s applications and limitations, as well as the specific potential hazards related to this tool. Following this rule will reduce the risk of electric shock, fire, and serious injury. 3. Do not place the battery near fire or heat. This will reduce the risk of explosion and possible injury. 4. Do not crush, drop or damage the battery pack.
OVERVIEW FIG. 1 Electrical contacts Battery-release button Power-indicator button Power indicator SPECIFICATIONS Battery Type Lithium-Ion Battery Voltage 20V DC Battery Weight 1.0 lbs. (0.46kg) Battery Capacity 2.
ASSEMBLY WARNING: If any part is broken or missing, DO NOT attempt to plug in the power cord, attach the battery, or operate the tool until the broken or missing part is replaced. Failure to do so could result in possible serious injury. WARNING: Do not attempt to modify this tool or create accessories not recommended for use with this tool. Any such alteration or modification is misuse and could result in a hazardous condition leading to possible serious injury.
OPERATION POWER INDICATOR (Fig. 2) This Lithium-Ion battery pack is equipped with a power indicator that displays the battery pack’s charge status. Press the powerindicator button to display the LED lights. The LED lights will stay lit for approximately 4 seconds. FIG. 2 NOTICE: The power indicator can be used whether the battery is attached to or removed from the tool.
OPERATION COLD WEATHER OPERATION When the battery pack is very cold, it may “pulse” for the first minute of use to warm itself. Put the battery pack on a tool and use the tool in a light application. After about a minute, the battery pack will have warmed itself and will operate normally. WHEN TO CHARGE THE BATTERY PACK 1. 2. 3. 4. 5. 6. The Lithium-Ion battery can be charged at any time and will not develop a “memory” when charged after only a partial discharge.
OPERATION LED FUNCTIONS OF CHARGER (FIG. 4) FIG. 4 LED INDICATOR BATTERY PACK HI / LO TEMP.
MAINTENANCE WARNING: To ensure safety and reliability, all repairs should be performed by a qualified service technician. WARNING: Always wear safety goggles or safety glasses with side shields when using compressed air to clean tool. If the operation is dusty, also wear a dust mask. WARNING: To avoid serious personal injury, always remove the battery pack from the tool when cleaning or performing any maintenance. BATTERIES: The battery pack is equipped with LithiumIon rechargeable batteries.
TROUBLESHOOTING PROBLEM CAUSE SOLUTION The battery pack isn’t charging Poor connected to charger. Reconnected the battery pack to the charger. The battery pack or charger is too hot. Allow the battery pack and charger to cool down.
NOTES Page 13
NOTES Page 14
© 2015 Menard, Inc.
