Instruction manual

TECHNICAL SPECIFICATIONS
3
AIR COMPRESSOR 8-GALLON (30.3 L) 058-9316-0
*CFM: Cubic feet per minute (The volumetric flow rate of a gas corrected to standardized conditions
of temperature and pressure).
RUNNING HORSEPOWER 1.5 HP
TANK SIZE 8 U.S. gallons
(30.3 L)
AIR DELIVERY (CFM*) @ 40 PSI 4.8
AIR DELIVERY (CFM*) @ 90 PSI 3.5
CUT-IN PRESSURE 105 PSI
CUT-OUT PRESSURE 135 PSI
PUMP DESIGN Oil-less, direct-drive, single-stage
MOTOR 3,400 RPM
POWER 120 V, 60 Hz, 12 A
WEIGHT 57 lb 3 oz
(26 kg)
POWER CORD SJT 16 AWG / 72" (1.83 m)
EXTENSION CORD SJT 12 AWG / Maximum 30' (9.1 m)
