PARTS LIST
8 U.S. GALLONS (30.3 L) AIR COMPRESSOR 058-9316-0
If any parts are missing or damaged, or if you have any questions, please call our toll-free helpline
at 1-800-689-9928.
No. Description Qty. No. Description Qty.
1 Nut M10 4 20 Fan 1
2 Rubber foot 2 21 Air filter 1
3 Bolt M10x20 2 22 Back shroud 1
4 Drain valve 4 23 Bolt M5x18 4
5 Air tank 1 24 Self-tapping screw ST3.9x17 4
6 Handle 1 25 Bolt M8x25 4
7 Thumbscrew 2 26 Washer Ø8 4
8 Check valve 1 27 Cushion pad 4
9 Regulator 1 28 Bolt M5x10 2
10 Relief valve 1 29 Lock washer 2
11 Quick coupler 1 30 Transfer tube 1
12 Pressure gauge 2 31 Pressure switch 1
13 Front shroud 1 32 Anchor nut 1
14 Switch retainer 1
33
Power cord 1
15 On/Off switch 1 34 Shoulder bolt 2
16 Elbow 1 35 Wheel 2
17 Pump/Motor assembly 1 36
Washer Ø10 6
18 Capacitor, 50 μf 1
37
Spring washer Ø10
2
19 Capacitor, 200 μf 1
