Replacement Parts

Models:

Item # Description MAC-36-BDF MAC-42-BDF MAC-48-BDF

1 Fan Blade Assembly 90-003-1060 90-003-2060 90-003-5250

2 Power Switch Holder 90-016-0100 90-016-0100 90-016-0100

3 Capacitor 90-004-1000 90-004-1000 90-004-2500

4 Power Switch 90-025-0100 90-025-0100 90-025-0110

5 Handle / Cord Wrap 90-006-0200 90-006-0200 90-006-0200

6 Power Cord 90-026-0050 90-026-0100 90-026-0100

7 Belt 90-037-0400 90-037-0450 90-037-0450

8 Fan Pulley 90-034-0300 90-034-0350 90-034-0350

9 Bearing Plate 90-013-0100 90-013-0100 90-013-0100

10 Motor Pulley 90-035-0350 90-035-0350 90-035-0355

Fan Shaft Assembly:

(1)

shaft, (2) bearings, (2) e-clips,

(2) washers

90-003-0660 90-003-0750 90-003-0755

12 Bearing E-Clip 90-065-0210 90-065-0220 90-065-0220

13 Fan Pulley E-Clip 90-065-0220 90-065-0220 90-065-0220

14 Bearing 90-040-0100 90-040-0100 90-040-0100

15 Bearing Housing 90-013-0200 90-013-0200 90-013-0105

16 Leg 90-002-0480 90-002-0480 90-002-0450

17 Wheel 70-041-1400 70-041-1400 70-041-1400

18 Wheel Axle 90-008-0485 90-008-0485 90-008-0485

19 Motor 90-030-0730 90-030-0830 90-030-0925

20 Wavy Spring Washer 90-066-0001 90-066-0001 90-066-0001
