92-2100 • MURANO Professional Studio Easel

ASSEMBLY INSTRUCTIONS

MAKE SURE CARTON CONTAINS THE FOLLOWING PARTS

WOOD PARTS

Quantity ........ Description ID#

2 ea. ........ Base Foot [1]

2 ea. ........ Base Foot Connectors [2]

2 ea. ........ Side Arms (1 Left & 1 Right) [3]

1 ea. ........ Upper Side Arm Connector [4]

1 ea. ........ Lower Side Arm Connector [5]

1 ea. ....... Center Ratchet Column [6]

1 ea. ........ Center Column [7]

1 ea. ........ Lower Canvas Tray [8]

2 ea. ........ Side Leg Angle Supports [9]

1 ea. ........ Upper Canvas Support [10]

HARDWARE PARTS

Quantity Description ID#

4 ea. ........ 6 x 60mm Carriage Bolts and T-nuts [A]

4 ea. ........ 6 x 50mm Carriage Bolts/Wash & T-nut [B]

1 ea. ........ 6 x 120mm Carriage Bolt and T-nut [C]

2 ea. ........ 6 x 45mm Wood Screws [D]

1 ea. ........ Loop-Pull Mechanism [E]

4 ea. ........ Small Wood Screws (with Loop-pull) [F]

1 ea. ........ 2.25” Knob - male [G]

2 ea. ........ Bolt 6x45mm, Knob & Washer [H]

2 ea. ........ Bolt 6x35mm, Knob & Washer [ I ]

TOOLS INCLUDED

Quantity ........ Description ID#

1 ea. ........ Flat Screwdriver [X]

1 ea. ........ Phillips Screwdriver [Y]

Page 1

Created June 06 RPI

[X]

[Y]

Side Arms

[ID# 3]

Base Foot Connectors

[ID# 2]

Base Foot [ID# 1]

Upper Side Arm Connector

[ID# 4]

Lower Side Arm Connector

[ID# 5]

Center

Ratchet

Column

[ID# 6]

Center

Column

[ID# 7]

Lower Canvas Tray

[ID# 8]

Side Leg Angle

Supports

[ID# 9]

Upper Canvas

Support

[ID# 10]

Carriage Bolt with Washer & T-Nut

6 x 50mm [ID# A]

Carriage Bolt with T-Nut

6 x 60mm [ID# B]

Carriage Bolt with T-Nut

6 x 120mm [ID# C]

6 x 45mm Wood

Screws

[ID# D]

Loop-pull Mechanism

[ID# E]

Small Wood

Screws

[ID# F]

2.25” Knob [ID# G]

Bolt 6 x 45mm, Knob & Washer

[ID# H]

Bolt 6 x 35mm, Knob & Washer

[ID# I]

Summary of content (4 pages)

PAGE 1
92-2100 • MURANO Professional Studio Easel ASSEMBLY INSTRUCTIONS MAKE SURE CARTON CONTAINS THE FOLLOWING PARTS WOOD PARTS Quantity ........ Description 2 ea......... Base Foot 2 ea......... Base Foot Connectors 2 ea......... Side Arms (1 Left & 1 Right) 1 ea......... Upper Side Arm Connector 1 ea......... Lower Side Arm Connector 1 ea. ....... Center Ratchet Column 1 ea......... Center Column 1 ea......... Lower Canvas Tray 2 ea......... Side Leg Angle Supports 1 ea.........
PAGE 2
For recommended assembly lay all wood parts on flat surface with all holes facing up. STEP 1. Assembling Base. Take each Base Foot [ID#1] (make sure wood hinges are on top.) along with each Base Foot Connectors - Make sure holes are on bottom of base. [ID#2]. Insert T-Nut from Carriage Bolt [ID# A] into hole in Base Foot Connector. See FIG 1. Repeat on all 4 sides. STEP 2. Assembling Base.
PAGE 3
STEP 10. Center column to Lower Canvas Tray Insert Center Column [ID#7] into oval slot on top edge of Lower Canvas Tray [ID#8]. Insert T-nut from part [ID#C]. See FIG 10. FIG 10 STEP 11. Center column to Lower Canvas Tray continued Insert Carriage bolt [ID#C] into hole in bottom end of Lower Canvas Tray [ID#8]. Using phillips screwdriver [ID# Y] tighten and secure bolt into T-nut. See FIG 11. 7 STEP 12.
PAGE 4
STEP 19. Side Arm Frame Assembly to Base Attachment STEP 20. Side Leg Angle Support to base assembly With Base laying face-up on carpeted ﬂoor, line up notched grooves on bottom ends of the Side Arm Frame Assembly with wooden supports on base. Secure with Knob, washer and 6x35mm bolt [ID#I]. Insert bolt through inside side of side arm through base foot, then back through other side of side arm. Attach washer and then secure with knob. Repeat with other side. See FIG 19.
