Instruction Manual

Freeze-dryer EPSILON 1-4 LSCplus
Freeze-dryer EPSILON 2-4 LSCplus
7 Malfunctions and error correction
Version 04/2014, Rev. 1.4 of 09/12/2014 • sb
85
Translation of the original operating manual
Pos: 161 /200 Ch rist /360 G T-BA L abo r-Pilot (STA NDA RDMODU LE )/070 S törun gen und Fe hlers uche 070 Stör ungen und Fehl ers uche == ===== ===== ==== ===== ===== = @ 25\ mod _14049 840 5603 9_68.d ocx @ 184 111 @ 1 @ 1

7 Malfunctions and error correction
Malfunctions are displayed in the dialog box "Process & equipment
messages" (see chapter 7.2 - "Process and error messages"). An acoustic
signal sounds when an error message is generated.
• Eliminate the source of the problem (see the following chapter).
• Acknowledge the error message.
Pos: 162 /01 0 Uni v ersal mod ule/L eerz ei le @ 0\m od_ 120 211624 450 0_0. doc x @ 11 4 @ @ 1
Pos: 163 /20 0 Ch rist/3 60 G T-BA L abo r-Pil ot (S TAND ARD MODU LE)/0 70 S törun gen und Fe hlers uche 070 -00 10 Allg em eine St öru ngen LSCpl us Alpha - Ga mma, E psilo n 1 -4_2 -4 @ 25 \mo d_1404 9840 570 04_ 68. docx @ 184125 @ 2 @ 1

7.1 General malfunctions
Type of error Possible reason Correction
No indication on the display • No power in the mains supply
(see chapter 7.1.1 - "Power
failure").
• Power cord is not plugged in.
• Fuses have tripped.
• The mains power switch is set
to off.
• Check the mains power supply
fuse.
• Plug in the power cord correctly.
• Check the on-site fuses
• Switch mains power switch ON.
The touchpanel does not react at all
or it does not react correctly
• The sensitivity of the touchpanel
is misadjusted.
• Contact the service department
(see chapter 7.3 - "Service
contact")
The password input fails • The password is not correct. • Inform the administrator.
• If you have lost the administrator
password: contact the service
department (see chapter 7.3 -
"Service contact")
Insufficient vacuum • Incorrect connection of the
small flange connection(s).
• Loosen the connection. Place
the centring ring with the inner
sealing ring in a centred manner
between the flange connections
and connect it with the clamping
ring. Ensure that the centring
ring neither slips out of place nor
gets jammed.
• Dirty or damaged lid or door
seal.
• Clean the lid or door seal and
replace it if necessary.
• The ground-in stopper of the
attached drying chamber is not
installed correctly.
• Grease the ground-in stopper
evenly and over the entire
sealing surface with vacuum
grease.
Leakage in the media drain valve • The media drain valve is soiled
with drying residues or wool
particles from cleaning cloths.
• The O-rings are worn
• Clean the media drain valve (see
chapter 8.1.1.3 - "Aeration
valve")and replace it if
necessary.
• Replace the O-rings.
Leakage in a rubber valve • The valve is soiled. • Check the valves individually
(see chapter 7.1.2.4 - "Rubber
valves")
