4 Storage and transport
Pos: 79 / 200 Chris t /36 1 GT-B A La bor -Pil ot (PRO JEK TE )/Eps ilon 2- 10D LS C plus S ta nda rd/040 Lage ru ng u nd Tra nspo rt/0 40- 001 0 Ab mess unge n u nd G ewicht E 2 -10D @ 2 5\m od_1 404 984892 615 _68. docx @ 18 637 9 @ 2 @ 1

4.1 Dimensions and weight
Epsilon 2-10D LSCplus
Height: 1,295 mm
Width: 1,190 mm
Depth (incl. vacuum flange connection): 850 mm
Weight: approx. 750 kg
Pos: 80 / 010 Uni ve rsalm odul e/Leerz eil e @ 0\mo d_1 202116 244 500 _0.doc x @ 114 @ @ 1
Pos: 81 / 200 Chris t/ 360 GT -BA La bor-P ilot (S TAN DA RDMODU LE) /04 0 La gerung und Tr ans port/ 040-00 20 La gerbedi n gungen @ 2 5\mo d_1 404 983 714695 _68. docx @ 18 348 1 @ 2 @ 1

4.2 Storage conditions
In order to ensure the protection against mechanical and climatic
influences, the guidelines of the German Federal Association for Wooden
Packages, Pallets, and Export Packaging (Bundesverband Holzpackmittel,
Paletten, Exportverpackung e.V.), the so-called HPE packaging guidelines,
must be applied when packing and storing the freeze-dryer.
The storage must be:
• dust-free
• dry
• free from excessive temperature fluctuations
• free from a mechanical load.
Pos: 82 / 010 Uni ve rsalm odul e/Leerz eil e @ 0\mo d_1 202116 244 500 _0.doc x @ 114 @ @ 1
Pos: 83 / 200 Christ /36 1 GT -BA La bor -Pi lot (PROJ EK TE )/Epsi lon 2-10D LS C plus S ta ndard/0 40 Lage ru ng und Trans port/ 040- 003 0 Tra nspo rthi nweis e E2 -10D @ 25\ mod_ 1404 984 893 417_68. doc x @ 18 639 3 @ 2 @ 1

4.3 Notes on transport
• Use suitable packaging for the transport, and if at all possible, the
original packaging.
• Install all transport safety devices (see chapter 4.5 - "Transport safety
devices").
CAUTION
The freeze-dryer Epsilon 2-10D LSCplus weighs approx. 750 kg!
CAUTION
The centre of gravity of the freeze-dryer is off-centre!
