Manual

Freeze-dryer EPSILON 2-10D LSCplus
10 Technical data
Version 04/2013, Rev. 1.5 of 16/12/2014 • sb
107
Translation of the original operating manual
Shelves
Shelf width: 350 R-vials 2R 4R 6R 8R 10R 15R 20R 25R 30R
Shelf length: 400  mm 35 45 40 45 45 60 55 65 75
Shelf  15 Ø mm 16 16 22 22 24 24 30 30 30
Number of
shelves
Area Distance The data indicate the maximum loading.
Substract 10% when using frames!
1 + 1 0,14 354 613 613 326 326 266 266 165 165 165
2 + 1 0,28 169 1226 1226 652 652 532 532 330 330 330
3 + 1 0,42 108 1839 1839 978 978 798 798 495 495 495
4 + 1 0,56 77 2452 2452 1304 1304 1064 660
5 + 1 0,70 59 Standard 3065
6 + 1 0,84 47 Only trays
7 + 1 0,98 38 Only trays
H-vials 5H 7H 8H 10H 15H 20H 25H 30H 50H 100H
 mm 41 41 47 54 59 58 58 63 73 95
Ø mm 21 22 23 25,5 27 32 36 36 43 52
Number of
shelves
Area Distance The data indicate the maximum loading.
Substract 10% when using frames!
1 + 1 0,14 354 363 326 290 243 218 147 117 117 83 54
2 + 1 0,28 169 726 652 580 486 436 294 234 234 166 108
3 + 1 0,42 108 1089 978 870 729 654 441 351 351 249
4 + 1 0,56 77 1452 1304 1160 972 872 588 468
5 + 1 0,70 59 Standard
6 + 1 0,84 47 Only trays
7 + 1 0,98 38 Only trays
Pos: 239 /01 0 Uni v ersal mod ule/L eerz ei le @ 0\m od_ 120 211624 450 0_0. doc x @ 11 4 @ @ 1
Pos: 240 /20 0 Ch rist/3 60 G T-BA L abo r-Pilot (STA NDA RDMODU LE )/1 00 Tech nis che D aten/ 100-0 010 U mgeb ungs bedin gun gen ----- ----- ----- --- ----- ----- --- ----- ----- ----- @ 25 \mod_1 404 9841 55772_ 68.d ocx @ 184 573 @ 2 @ 1
 10.1 Umgeb ungs bedi ngu nge n
10.1 Ambient conditions
Pos: 241 /20 0 Ch rist/3 60 G T-BA L abo r-Pi lot (STAN DAR DMODU LE )/1 00 Tech nis che D ate n/10 0-0010 Um geb ungs bedin gungen Tex t @ 2 5\m od_140 498 415 4817 _68 .docx @ 1 84559 @ @ 1
 10.1 Umgeb ungs bedi ngu nge n
• The figures are valid for an ambient temperature of +20°C.
• Allowable ambient temperature +10 °C to +25 °C.
• Max. humidity 85% (non-condensing) at +25°C.
Pos: 242 /01 0 Uni v ersal mod ule/L eerz ei le @ 0\m od_ 120 211624 450 0_0. doc x @ 11 4 @ @ 1
Pos: 243 /20 0 Ch rist/3 60 G T-BA L abo r-Pi lot (STAN DAR DMODU LE )/1 00 Tech nis che D ate n/10 0-0020 Techni sc he D okum ent ation @ 25 \mod_1 404 984 156 884_ 68. docx @ 18458 7 @ 2 @ 1

10.2 Technical documentation
The technical documentation of this freeze-dryer (e.g. circuit diagram,
cooling system ) and the safety data sheets of the manufacturers of
refrigerant and heat transfer medium is not attached to this operating
manual.
You can order these documents from our service department.
