6.1 Provision Application
Application Files Required
6.1.1.1 8880-027_Application_Provision_Tool_CVL
6.1.1.2 8880-029_AutoFirmwareProgramming
Unzip both files to the C:\ drive root directory.
Connect the Computer / Tablet to the wireless monitor using custom cable, shown
in pictures below.
Tablet with cable
(Connection End 1)
Custom Cable
USB-B to Mini-USB
MGL Light Fixture with cable
(Connection End 2)
Figure 3: Wireless Radio Connected to Laptop using custom cable
Make sure the wireless monitor amber LED turns “On” located (in underside) next
to the mini USB connector. The LED will blink the firmware code revision.
o Run the Application
To open application, click the executable file called “cvprovision.exe” located in the
“8880-027_ Application_ Provision_ Tool_ CVL”. Create a shortcut to this application
exe file on your desktop.
o Screen Layout
The provision application has the 3 tabs.
