DESCRIPTION

4 to 1 is a preblended mixture of ﬁnely graded sand and Portland cement used

for thick-bed mortar installations. 4 to 1 ﬂattens and levels an existing substrate

before the installation of tile and stone.

FEATURES AND BENEFITS

• Screedandlevelfrom3/8"to3"(10mmto7,5cm)

• Idealforoatingshowerbases

• MixwithwaterorPlanicrete

INDUSTRY STANDARDS AND APPROVALS

LEED(Version3.0)PointsContribution LEED Points

MRCredit5,RegionalMaterials* ...................................Up to 2 points

*Using this MAPEI product may help contribute to LEED certiﬁcation of projects

in the categories shown above. Points are awarded based on contributions of

all project materials.

WHERE TO USE

• Floatingshowerbases

• Canbedirectlybondedorusedasadetachedoatingmortarbedover

acleavagemembraneorwaterproongmembrane

• Foruseinbothresidentialandcommercialapplicationsindryandwet

areas

• Mixeswithwater.Forincreasedperformanceandreducedporosity,

mixwithMAPEI’sPlanicrete AC latex admixture.

LIMITATIONS

• 4 to 1canbemixedwithwaterformostinteriorconditions.Forbetter

performanceorforexteriororheavy-dutywetareas,mix 4 to 1with

Planicrete ACinsteadofwithwater.Fordetails,seetheTechnicalData

SheetforPlanicrete AC.

• SeeANSIA108.1industrystandardfordetailsonmortarbedinstallations.

• Fordirect-bondapplications,theconcretesurfaceshouldhaveaproleof

CSP#3to#5orgreater.Thesurfacemustbeprimedwithaslurrybond

coatmixture(see“Mixing”sectionfordetails).

• Wood-framestructuresmustbedesignedtohandletheloadsofoating

mortarbedsandtileassemblies.Ifthesuitabilityofthestructureisunclear,

consult a structural engineer or design consultant.

• Forcoveringlargeareas,pleasecontactTechnicalServicesfor

recommendations.

ConsultMAPEI’sTechnicalServicesDepartmentforinstallationrecommendations

regarding substrates and conditions not listed.

SUITABLE SUBSTRATES

• Curedconcreteoors

• Adequatelydesignedwoodframeoorsystems(seehandbookoftheTile

CouncilofNorthAmerica[TCNA]orTerrazzo,Tile&MarbleAssociationof

Canada[TTMAC]fordetails)

SURFACE PREPARATION

• Fordirect-bondapplications,thesurfacemustbecleanandporouswitha

proleofCSP#3to#5orgreater.

to 1

™

Mud Bed

Mix

4 to 1

™

Mud Bed

Mix

Sand and Cement

Mortar Mix

Version: Jan. 25, 2010

Summary of content (4 pages)

PAGE 1
Version: Jan. 25, 2010 d e B 4 x d i u M M 1 to ™ Sand and Cement Mortar Mix Description Limitations 4 to 1 is a preblended mixture of finely graded sand and Portland cement used for thick-bed mortar installations. 4 to 1 flattens and levels an existing substrate before the installation of tile and stone. • 4 to 1 can be mixed with water for most interior conditions. For better performance or for exterior or heavy-duty wet areas, mix 4 to 1 with Planicrete AC instead of with water.
PAGE 2
ed B 4 d ix Mu M to 1 ™ • For details on preparing surfaces to receive ceramic tile and natural stone, see MAPEI’s “Surface Preparation Requirements” document for tile and stone installations. 2. Apply a cleavage membrane or slip sheet (6 mils [0,15 mm] of polyethylene or 15 lbs. [6,80 kg] of roofing felt) to the substrate. 3. Lay out rolled or self-furred sheets of 2" x 2" (5 x 5 cm) 16-gauge galvanized wire mesh throughout installation. Overlap mesh by 2" (5 cm) and connect using wire ties. 4.
PAGE 3
Product Performance Properties at 73°F (23°C) and 50% relative humidity Laboratory Tests Results Pot life at 68°F (20°C) 90 to 120 minutes Application temperature range 40°F to 95°F (4°C to 35°C) Compressive strength (ASTM C109, 28 days) > 2,500 psi (17,2 MPa) Pull-out rupture (28 days) Mixed with water > 72 psi (0,50 MPa) Mixed with Planicrete AC > 260 psi (1,79 MPa) Color Gray Cleanability With water while fresh Shelf Life Shelf life 1 year when stored in a dry location, sealed in origina
PAGE 4
ed B d ix Mu M to 1 ™ 4 Related Documents See TCA or TTMAC handbooks for most recent information and detail drawings regarding applicable mortar beds. Refer to MAPEI’s Material Safety Data Sheet (MSDS) for specific data related to VOCs, health and safety, and handling of product. Statement of Responsibility Before using, user shall determine the suitability of the product for its intended use and user alone assumes all risks and liability whatsoever in connection therewith.
