Part Number 80-1479-3 7/10 41
Ice machine cleaner is used to remove lime scale and
mineral deposits. Ice machine sanitizer disinfects and
removes algae and slime.
Step 1 Set the toggle switch to the OFF position after
ice falls from the evaporator at the end of a Harvest
cycle. Or, set the switch to the OFF position and allow
the ice to melt off the evaporator.
Step 2 Remove top cover. This will allow easiest
access for adding cleaning and sanitizing solutions.
Step 3 Remove all ice from the bin.
Step 4 Place the toggle switch in the CLEAN
position. The water will flow through the water dump
valve and down the drain. Wait until the water trough
refills and water flows over the evaporator, then add
the proper amount of ice machine cleaner.
Continued on next page …
!
Caution
Never use anythin g to fo rce ice fro m the
evaporator. Damage may result.
Model Amount of Cleaner
S300/S320/S420 3 ounces (90 ml)
S450/S500/S600/S850/
S1000/S1200
5 ounces (150 ml)
S1400/S1600/S1800 9 ounces (265 ml)
S3300 16 ounces (475 ml)
