40 Part Number 80-1479-3 7/10
Procedure to Clean Heavily Scaled
Ice Machines
Ice machines that are heavily scaled or have not been
cleaned on a regular basis will need to run this
procedure.
GENERAL
Clean and sanitize the ice machine every six months
for efficient operation. If the ice machine requires more
frequent cleaning and sanitizing, consult a qualified
service company to test the water quality and
recommend appropriate water treatment. The ice
machine must be taken apart for cleaning and
sanitizing.
CLEANING PROCEDURE
!
Caution
Use o nly Ma nitowoc approved Ice Machine
Cleaner and Sanitizer fo r this app lication
(Manitowoc Cleaner part number 94-05 46-3 and
Manitowoc Sanitizer part number 94-0565-3). It is
a violation of Federal law to use these solutions in
a manne r inconsistent wit h thei r la beling. Read
and u nderstand a ll labels printed on b ottles
before use.
!
Caution
Do n ot mix Cle aner and Sani tizer solu tions
together. It is a vi olation of F ederal l aw to u se
these solu tions in a ma nner in consistent with
their labeling.
!
Warning
Wear rubb er gl oves an d safety gog gles (a nd/or
face shie ld) when handling ice machine Cleaner
or Sanitizer.
