Part Number 80-1479-3 7/10 33
Step 3 Remove all ice from the bin.
Step 4 Place the toggle switch in the CLEAN
position. The water will flow through the water dump
valve and down the drain. Wait until the water trough
refills and water flows over the evaporator, then add
the proper amount of ice machine cleaner.
Step 5 Wait until the clean cycle is complete
(approximately *35 minutes). then place the toggle
switch in the OFF position and disconnect power to
the ice machine (and dispenser when used).
NOTE: *S3300 Only - 80 minutes..
Step 6 Remove parts for cleaning.
Please refer to the proper parts removal for your
ice machine.
Single Evaporator Ice Machines - page 34.
Quad Evaporator Ice Machines - page 35.
Model Amount of Cleaner
S300/S320/S420 3 ounces (90 ml)
S450/S500/S600/S850/
S1000/S1200
5 ounces (150 ml)
S1400/S1600/S1800 9 ounces (265 ml)
S3300 16 ounces (475 ml)
!
Warning
Disconnect the electric power to the ice machine
at the electric service switch box.
