Part Number 80-1479-3 7/10 263
SD1892N
Dice Cube, Remote Condenser Air-cooled with a
Manufacture Date After 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
-20/-29 to 70/21 9.4-10.7 10.3-11.7 11.1-12.6
1 - 2.5
80/27 9.5-10.8 10.5-11.9 11.3-12.8
90/32 10.0-11.4 11.1-12.6 12.0-13.6
100/38 10.8-12.2 12.0-13.6 13.0-14.8
110/43 11.7-13.3 13.1-14.9 14.3-16.3
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
12
1 Based on average ice slab weight of 13 - 14.125 lb
2 Ratings with JC1395 condenser
50/10 70/21 90/32
-20/-29 to 70/21 1750 1610 1510
80/27 1730 1590 1490
90/32 1650 1510 1410
100/38 1550 1410 1310
110/43 1440 1300 1200
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
-20/-29 to
50/10
230-265 38-24 100-160 70-85
70/21 240-265 40-26 110-170 70-90
80/27 250-275 45-28 110-180 70-95
90/32 250-300 52-29 110-180 70-95
100/38 275-335 55-31 110-185 75-100
110/43 310-385 55-32 120-190 80-110
