Part Number 80-1479-3 7/10 261
SY1805W
Half Dice Cube, Self-Contained Water-cooled with a
Manufacture Date After 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.6-9.8 9.1-10.4 10.6-12.1
1 - 2.5
80/27 8.7-10.0 9.3-10.6 10.8-12.3
90/32 8.8-10.0 9.4-10.7 10.9-12.4
100/38 8.9-10.1 9.5-10.8 11.1-12.6
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 13 - 14.125 lb.
50/10 70/21 90/32
70/21 1890 1790 1570
80/27 1860 1760 1540
90/32 1850 1750 1530
100/38 1830 1730 1510
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 230-240 45-25 145-165 65-80
70/21 220-280 40-26 160-180 70-90
80/27 230-240 45-25 145-165 65-80
90/32 240-270 50-25 150-190 70-90
100/38 240-270 55-25 155-190 70-90
110/43 240-270 55-25 155-190 70-90
