260 Part Number 80-1479-3 7/10
SD1803W
Dice Cube, Self-Contained Water-cooled with a
Manufacture Date After 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.6-9.8 9.6-11.0 10.8-12.2
1 - 2.5
80/27 8.8-10.0 9.8-11.2 11.0-12.5
90/32 8.8-10.1 9.9-11.3 11.1-12.6
100/38 9.0-10.3 10.1-11.5 11.3-12.9
110/43 9.1-10.4 10.2-11.7 11.5-13.1
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 13 - 14.125 lb.
50/10 70/21 90/32
70/21 1880 1710 1550
80/27 1850 1680 1520
90/32 1840 1670 1510
100/38 1810 1640 1480
110/43 1790 1620 1460
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 230-240 45-25 145-165 65-80
70/21 220-280 40-26 160-180 70-90
80/27 230-240 45-25 145-165 65-80
90/32 240-270 50-25 150-190 70-90
100/38 240-270 55-25 155-190 70-90
110/43 240-270 55-25 155-190 70-90
