Part Number 80-1479-3 7/10 257
SD1802A
Dice Cube, Self-Contained Air-cooled with a Manufacture
Date After 0910 (October 2009)
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.9-10.1 9.7-11.0 10.5-12.0
1 - 2.5
80/27 9.7-11.0 10.6-12.1 11.6-13.2
90/32 10.5-11.9 11.5-13.1 12.7-14.4
100/38 11.5-13.1 12.8-14.5 14.2-16.1
110/43 12.9-14.6 14.5-16.4 16.3-18.4
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 13 - 14.125 lb.
50/10 70/21 90/32
70/21 1830 1700 1580
80/27 1700 1570 1450
90/32 1590 1460 1340
100/38 1460 1330 1210
110/43 1320 1190 1070
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 40-24 150-180 70-90
70/21 220-280 40-26 160-180 70-90
80/27 240-290 50-27 160-180 70-90
90/32 260-330 50-27 180-200 80-100
100/38 300-370 54-28 200-220 90-115
110/43 330-410 60-30 220-250 100-130
