Part Number 80-1479-3 7/10 249
SY1405W
Half Dice Cube, Self-Contained Water-Cooled With a
Manufacture Date of 0905 (May 2009) or Later
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.6-9.6 9.6-10.7 10.9-12.2
0.75-2.0
90/32 8.8-9.9 9.8-10.9 11.2-12.5
100/38 9.0-10.0 10.1-11.2 11.4-12.7
110/43 9.1-10.1 10.2-11.4 11.6-12.9
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10 - 11 lb.
50/10 70/21 90/32
70/21 1430 1300 1160
90/32 1395 1275 1130
100/38 1375 1245 1115
110/43 1360 1230 1100
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 230 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 85 140 510
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 225-235 40-28 160-175 70-90
70/21 225-235 42-28 160-175 75-100
80/27 230-260 42-28 170-195 80-105
90/32 240-270 42-28 180-200 85-110
100/38 250-280 43-30 185-200 90-110
110/43 250-285 44-31 190-205 90-115
