248 Part Number 80-1479-3 7/10
SD1403W
Dice Cube, Self-Contained Water-Cooled With a
Manufacture Date of 0905 (May 2009) or Later
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.8-10.1 9.8-11.1 11.2-12.8
0.75-2.0
80/27 8.9-10.2 9.9-11.2 11.3-12.9
90/32 9.0-10.2 9.9-11.3 11.4-13.0
100/38 9.0-10.3 10.0-11.4 11.6-13.2
110/43 9.1-10.4 10.1-11.5 11.7-13.3
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10.25 - 11.5 lb.
50/10 70/21 90/32
70/21 1430 1310 1160
90/32 1410 1290 1140
100/38 1400 1280 1130
110/43 1390 1270 1120
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 230 PSIG discharge pressure
50/10 70/21 90/32
Gal/100 lbs. of Ice 82 143 430
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 40-24 150-180 70-90
70/21 220-280 40-26 160-180 70-90
80/27 240-290 50-27 160-180 70-90
90/32 260-330 50-27 180-200 80-100
100/38 300-370 54-28 200-220 90-115
110/43 330-410 60-29 220-250 100-130
