244 Part Number 80-1479-3 7/10
SY1404A
Half Dice Cube, Self-Contained Air-Cooled With a
Manufacture Date of 0905 (May 2009) or Later
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.7-9.9 9.6-11.0 10.2-11.6
0.75 - 2.5
80/27 9.1-10.4 10.1-11.5 10.8-12.3
90/32 9.7-11.0 10.8-12.3 11.6-13.2
100/38 10.6-12.1 11.9-13.6 12.8-14.6
110/43 11.9-13.6 13.6-15.4 14.7-16.7
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10.25 - 11.5 lb.
50/10 70/21 90/32
70/21 1450 1330 1260
80/27 1390 1270 1200
90/32 1320 1200 1130
100/38 1220 1100 1030
110/43 1100 980 910
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 40-24 150-180 70-90
70/21 220-280 40-26 160-180 70-90
80/27 240-290 50-27 160-180 70-90
90/32 260-330 50-27 180-200 80-100
100/38 300-370 54-28 200-220 90-115
110/43 330-410 60-29 220-250 100-130
