Specifications

Part Number 80-1479-3 7/10 243
SD1402A
Dice Cube, Self-Contained Air-Cooled With a
Manufacture Date of 0905 (May 2009) or Later
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 8.8-10.0 9.6-11.0 10.3-11.7
0.75 - 2.5
80/27 9.5-10.9 10.4-11.9 11.2-12.8
90/32 10.1-11.5 11.1-12.7 12.0-13.7
100/38 11.3-12.9 12.6-14.3 13.7-15.6
110/43 13.0-14.7 14.5-16.5 16.1-18.2
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 10.25 - 11.5 lb.
50/10 70/21 90/32
70/21 1440 1330 1250
80/27 1340 1240 1160
90/32 1270 1170 1090
100/38 1150 1050 970
110/43 1020 920 840
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 220-280 40-24 150-180 70-90
70/21 220-280 40-26 160-180 70-90
80/27 240-290 50-27 160-180 70-90
90/32 260-330 50-27 180-200 80-100
100/38 300-370 54-28 200-220 90-115
110/43 330-410 60-29 220-250 100-130
