Part Number 80-1479-3 7/10 241
SY1205W
Half Dice Cube, Self-Contained Water-cooled After Serial
Number 110697023
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
CONDENSER WATER CONSUMPTION
OPERATING PRESSURES
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 7.7-8.7 8.5-9.4 9.8-10.9
0.75-2.0
80/27 7.8-8.7 8.5-9.6 9.9-11.0
90/32 7.8-8.7 8.6-9.7 9.9-11.1
100/38 7.9-8.8 8.8-9.8 10.0-11.1
110/43 7.9-8.9 8.9-9.9 10.1-11.2
Air Temp. Around Ice
Machine °F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 5.75 -6.5 lb
50/10 70/21 90/32
70/21 1170 1085 955
80/27 1165 1075 950
90/32 1160 1065 945
100/38 1155 1050 940
110/43 1145 1040 935
Air Temp. Around Ice
Machine 90°F/32°C
Water Temperature °F/°C
1
1 Water regulating valve set to maintain 225 PSIG discharge pressure
50/10 70/21 90/32
Gal/24 Hours 770 1560 5700
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 215-225 40-20 150-175 70-85
70/21 215-225 42-20 150-185 70-90
80/27 235-250 44-22 160-190 80-95
90/32 240-270 45-22 170-195 80-105
100/38 240-280 50-22 175-205 85-110
110/43 240-280 50-23 180-215 85-115
