24 Part Number 80-1479-3 7/10
REMOTE CONDENSER LINE SET INSTALLATION
Ice Machine
Remote Single
Circuit
Condenser
Line Set*
S500 JC0495
RT-20-R404A
RT-35-R404A
RT-50-R404A
S600
S800
S1000
JC0895
RT-20-R404A
RT-35-R404A
RT-50-R404A
S1400
S1600
S1800
JC1395
RL-20-R404A
RL-35-R404A
RL-50-R404A
*Line Set Discharge Line Liquid Line
RT 1/2" (1.27 cm) 5/16" (.79 cm)
RL 1/2" (1.27 cm) 3/8" (.95 cm)
Air Temperature Around the Condenser
Minimum Maximum
-20°F (-29°C) 120°F (49°C)
Important
Manitowoc remote systems are only approved
and warranted as a complete new package.
Warranty on the refrigeration system will be
void if a new ice machine head section is
connected to pre-existing (used) tubing or
remote condensers or vice versa.
