234 Part Number 80-1479-3 7/10
SD1092N
Dice Cube, Remote Condenser Air-cooled After Serial
Number 110697023
Characteristics may vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
24 HOUR ICE PRODUCTION
OPERATING PRESSURES
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
1 Times in minutes
Water Temperature °F/°C
50/10 70/21 90/32
70/21 6.5-7.6 7.1-8.3 7.9-9.1
0.75-2.0
90/32 7.5-8.7 8.0-9.3 9.1-10.5
100/38 8.1-9.3 8.9-10.2 9.8-11.3
110/43 8.7-10.1 9.6-11.1 10.8-12.4
Air Temp. Entering
Condenser
°F/°C
Water Temperature °F/°C
1
1 Based on average ice slab weight of 5.75 -6.5 lb
50/10 70/21 90/32
70/21 1030 960 885
90/32 920 870 780
100/38 865 800 730
110/43 810 745 675
Air Temp.
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
1 Suction pressure drops gradually throughout the freeze cycle
50/10 200-220 35-22 100-165 70-85
70/21 220-260 40-24 100-170 70-90
80/27 245-285 45-25 100-170 70-95
90/32 250-300 50-27 100-170 70-95
100/38 285-330 60-32 130-180 75-100
110/43 300-375 60-32 130-190 80-100
